PABLI  |  13W

Product category: Adjustable spotlight with recessed base
Tilting: 90°
Power: 13W
Light Source: cob LED
CRI > 90
CCT: 2700K – 3000K – 4000K
Luminous flux: 1207 lm
Optic: Backward lens optic
Beam angle: 36° – 60°
Driver: External, not included
Input: Max. DC 37 V / 350 mA
Material: Extruded/turned aluminum
IP grade: IP20
Insulation class: III
Surface treatment: Plated / Electrostatic spray processing
External finish: White – Black – Brass
Inner ring finish: White – Black
Spot size: Ø 40 x H 155 mm
Base size: Ø 65 x 30 mm
Height: 200 / 400 mm
Cut off: Ø 55 mm

PABLI 360  |  DIFFUSING

Power: 13W
Luminous flux with diffuser: 908 lm
Optic: Solid PMMA
Beam angle: Diffusing (D1 – D2)
External finish: White – Black – Brass
Spot size: Ø 40 x H 177 mm
Base size: Ø 65 x 30 mm
Height: 200 / 400 mm
Cut off: Ø 55 mm

certificazioni spot LED PABLI

PABLI SPOT

misure LL-PABLI 13W

PABLI DIFFUSER

dimensioni PABLI DIFFUSER

DIFFUSER OPTIONS

PABLI optic

PABLI SPOT

misure LL-PABLI 13W

PABLI DIFFUSER

dimensioni PABLI DIFFUSER

DIFFUSER OPTIONS

PABLI optic
certificazioni spot LED PABLI

PHOTOMETRIC SPECIFICATIONS

photometric data
blank
CODE PABLI SPOT

LL-PABLI-X-X1-X2-X3-X4-X5



X POWER: 13

X1 HEIGHT: 200 / 400

X2 EXTERNAL FINISH: B / / BR

X3 INNER RING FINISH: B / W

X4 CCT: SW / WW / NW

X5 BEAM ANGLE: 36° / 60°

CODE PABLI 360

LL-PABLI-360-X-X1-X2-X3-X4



X POWER: 13

X1 HEIGHT: 200 / 400

X2 EXTERNAL FINISH: B / / BR

X3 CCT: SW / WW / NW

X4 BEAM ANGLE: D1 – D2

PABLI optic
